| Place of Origin: | China |
| Brand Name: | Huawei |
| Model Number: | S5732-H48UM2CC |
Description
Huawei CloudEngine S5732-H48UM2CC is a flagship full gigabit PoE++switch designed for ultra large scale deployment in the Wi Fi 6/7 era. Its core value lies in "48 high-density 10 Gigabit Ethernet ports+60W PoE++power supply+1320Mpps performance+25GE/100GE uplink+on-board AC+VXLAN" - covering a wider area with 48 high-density 10 Gigabit Ethernet ports, ensuring a large number of high-power devices with 60W power supply, eliminating forwarding bottlenecks with ultra-high performance, ensuring that the next 5-10 years are not outdated with 25GE/100GE uplink, and achieving deep integration of wired and wireless with on-board AC. It is the top configuration choice with the highest port density among all the switches we have discussed so far, and is most suitable as the access layer for ultra large scale Wi Fi 6/7 APs.
Pictures
Specification
|
Item |
Description |
|---|---|
|
Memory (RAM) |
4 GB |
|
Flash |
2 GB in total. To view the available flash memory size, run the display version command. |
|
Mean time between failures (MTBF) |
42.49 years |
|
Availability |
> 0.99999 |
|
Service port surge protection |
Common mode: ±7 kV |
|
Power supply surge protection |
|
|
Dimensions (H x W x D) |
|
|
Weight (including package) |
Without power modules: 9.53 kg (21.01 lb) Including one power module: 10.57 kg (23.3 lb) |
|
Stack ports |
Any Ethernet electrical ports (10GE), optical ports on the front panel (25GE/40GE/100GE), or optical ports on the card (10GE/25GE/40GE/100GE) |
|
RTC |
Supported |
|
RPS |
Not supported |
|
PoE |
Supported |
|
Rated voltage range |
|
|
Maximum voltage range |
|
|
Maximum power consumption (100% throughput, full speed of fans) |
|
|
Typical power consumption (30% of traffic load, tested according to ATIS standard) |
210 W (without card) |
|
Operating temperature |
-5°C to +45°C (23°F to 113°F) at an altitude of 0-1800 m (0-5906 ft.)
NOTE:
When the altitude is 1800-5000 m (5906-16404 ft.), the highest operating temperature reduces by 1°C (1.8°F) every time the altitude increases by 220 m (722 ft.). The switch cannot be started when the ambient temperature is lower than 0°C (32°F). The operating temperature of the switch is -5°C to 40°C (23°F to 104°F) when it uses QSFP-100G-ER4 optical module. |
|
Storage temperature |
-40°C to +70°C (-40°F to +158°F) |
|
Noise under normal temperature (27°C, sound power) |
|
|
Relative humidity |
5% to 95%, noncondensing |
|
Operating altitude |
0-5000 m (0-16404 ft.) |
|
Certification |
|
|
Part number |
02353SJT-020 02353SJT-021 02353SJT-023 02353SJT-024 |
