Huawei Fusion Server
>
Huawei Fusionserver 5288 V5 V3 4u H52m-03 5288v3 Ipfs Fil Rack Server

Huawei Fusionserver 5288 V5 V3 4u H52m-03 5288v3 Ipfs Fil Rack Server

Product Details:
Place of Origin: China
Brand Name: Huawei
Certification: CQC
Model Number: Fusionserver 5288 V5 V3
Detail Information
Place of Origin:
China
Brand Name:
Huawei
Certification:
CQC
Model Number:
Fusionserver 5288 V5 V3
Product Name:
Rack Server
Number Of Memory Slots:
16
Form Factor:
4U
Dimensions (W X D X H):
447×748×175mm
Expansion Capability:
6 PCIe Slots
Memory Type:
DDR4
Highlight:

High Light

Highlight:

Huawei Fusionserver 5288 V5 V3

,

5288 V5 V3 4u H52m-03

,

5288v3 Ipfs Fil Rack Server

Trading Information
Minimum Order Quantity:
1 unit
Price:
1712-2230 USD
Packaging Details:
Original brand carton
Delivery Time:
7 work days
Payment Terms:
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability:
1000 units
Product Description

Huawei Fusionserver 5288 V5 V3 4u H52m-03 5288v3 Ipfs Fil Rack Server



Description


Huawei FusionServer 5288 V3 is a 4U dual-socket storage rack server launched by Huawei. It utilizes the Intel Xeon E5-2620 v4 processor, with a base frequency of 2.1GHz and an intelligent turbo frequency that can reach 3.0GHz. The server comes standard with 16GB DDR4 memory and supports a maximum memory capacity of 1TB. It provides 24 3.5-inch disk bays and supports 12G SAS technology. Its features include DEMT energy-saving technology, power capping technology, high-voltage direct current power supply technology, and PID control cooling speed regulation strategy, making it suitable for scenarios such as cold data storage, video surveillance, and cloud storage. The server is equipped with Huawei Hi1710 management chip, supporting remote control and deep pre-fault detection



Pictures


Huawei Fusionserver 5288 V5 V3 4u H52m-03 5288v3 Ipfs Fil Rack Server 0

Specification




Server Model
FusionServer 5288
Form Factor
4U Rack Server
Processors
1/2 3rd Generation Intel® Xeon® scalable processor (Ice Lake) (8300 / 6300 / 5300 / 4300 Series) , up to 270W



Local Storage
Various hard disk configurations are supported. The hard disks are hot swappable:
· 36 to 44 3.5-inch SAS/SATA HDDs and 4 NVMe SSDs
· 24 x 3.5-inch SAS/SATA front hard disks
· 4 3.5-inch SAS/SATA internal hard disks
· 16 3.5-inch SAS/SATA hard disks and four 2.5-inch SAS/SATA/NVMe rear hard disks
· 12 3.5-inch SAS/SATA disks and eight 2.5-inch rear hard disks (4 x 2.5″ HDDs + 4 x 2.5″ SAS/SATA/NVMe)
Flash storage:
· Dual M.2 SSDs

RAID support
Supports RAID 0, 1, 5, 50, 6, and 60, cache supercapacitor protection, RAID level migration, disk roaming, self-diagnosis, and
web-based remote configuration, and multiple network expansion capabilities
Network
OCP 3.0 NIC
The two FLEX I/O card slots support two OCP 3.0 NICs, which can be configured as required
Supports multiple OCP 3.0 NICs
Supports hot swap

PCIe Expansion
A maximum of 11 PCIe 4.0 slots, including one dedicated PCIe slot for the RAID controller card, two dedicated FLEX I/O slots for
OCP3.0, and eight standard PCIe 4.0 slots
Chip Set
Intel® C621A
Fan Modules
Four hot-swappable fans, supporting N+1 redundancy
Height X Width X Depth
Chassis dimensions: 175 mm x 447 mm x 790 mm





Power Supply Units
2 redundant hot-swappable PSUs are configured in 1+1 redundancy mode. The optional specifications are as follows:
· 900W AC Platinum/Titanium power supply (Input: 100–240 V AC or 192–288 V DC)
· 1500 W AC Platinum PSU
· 1000 W (input: 100 V AC to 127 V AC)
· 1500 W (input: 200–240 V AC or 192–288 V DC)
· 2000 W AC Platinum PSU
· 1800 W (input: 200–220 V AC or 192–200 V DC)
· 2000 W (input: 220–240 V AC or 200–288 V DC)

Huawei Fusionserver 5288 V5 V3 4u H52m-03 5288v3 Ipfs Fil Rack Server 1
